Type B 30ma 63a 4Pole Residual Current Circuit Breaker

Place of Origin : Zhejiang, China

Brand Name : SUNTREE

Model Number : SCB8LT-100H

Supply Ability : 4000 Pack/Packs per Month

Packaging Details : standard packing

MOQ : 30 Piece/Pieces

Price : $4.00 - $22.00 / Piece

Type : Residual Current

Poles Number : 4P

Product name : residual current circuit breaker

Rated current : 6-100A

Rated voltage : 230V

Breaking capacity : 6KA/10KA

Rated frequency : 50/60 Hz

Poles : 4

Material : thermosetting

Application : Short-circuit Protection

Brand : Suntree

Web : www.chinasuntree.com

Port : shanghai/ningbo

Contact Now

Type B residual Current Circuit Breaker 4 Pole 63a 30ma rcd

Product Description
1. with short circuit/ overload protection and isolating function
2. When the grid Leakage current is over setting range, the RCBO will trip to cut off power within very short time to ensure personal safety and Avoid accidents due to leakage
3. Using with prepaid energy meter together, it will be turn off automatic when own cost and turn on by manual after recharge
Product Parameters
Type
SCB8LT-100H
Pole
4P
Rated Current
6A-100A
Rated Voltage
230V
Rated breaking vapacity
6KA/10KA
Rated residual action current
0.03A/0.05A/0.1A
Rated residual making and breaker capacity
2000A
Delay time for control signature
1s<t<4s
Re-closing time
t<30s
Electrical Life
4000Times
Mechanical
20000Times
Certificates
TUV,CE,IEC,GB
Standard
GB16917.1
Material
thermosetting
Installation
On symmetrical DIN rail 35mm / Panel mounting

Type B 30ma 63a 4Pole Residual Current Circuit Breaker

Product Details Show
Type B 30ma 63a 4Pole Residual Current Circuit Breaker
Recommend Products
Type B 30ma 63a 4Pole Residual Current Circuit Breaker
Type B 30ma 63a 4Pole Residual Current Circuit Breaker
Type B 30ma 63a 4Pole Residual Current Circuit Breaker
Type B 30ma 63a 4Pole Residual Current Circuit Breaker
Type B 30ma 63a 4Pole Residual Current Circuit Breaker
Type B 30ma 63a 4Pole Residual Current Circuit Breaker
Type B 30ma 63a 4Pole Residual Current Circuit Breaker
Type B 30ma 63a 4Pole Residual Current Circuit Breaker
Company Profile
XinChi Electric Group Co., Ltd is a group company,There are four branch companies subordinate to it. Registered trademark is "suntree".
Main Products: AC&DC Circuit breaker, Solar system parts,SISO-40 Solar Inverter/Cable
,Connector,Contactors, MCCB, ATS auto transfer switch, DC Combiner Box, Waterproof distribution box,etc.
Quality &Standards:Products are producted per ISO9001:2008, IEC60947, IEC60898,CB, SAA, TUV,CE,SONCAP,ROHS, Nemko, PCT,CCC etc
Main markets:Australia,New Zealand,&other worldwide markets
Type B 30ma 63a 4Pole Residual Current Circuit Breaker
Type B 30ma 63a 4Pole Residual Current Circuit Breaker
Type B 30ma 63a 4Pole Residual Current Circuit Breaker
FAQ
Q: How can i trust you and your company ?
A: Suntree is a group company, we have 6 subcompanies. Have cooperation with LS, EKF the world-class companies. Our company over 500 employees, products pass CE,IEC,TUV,SAA, RCM, ROHS certificates.
Q: How long is your products warranty ?
A: The warranty period of our products is 2 Years.
Q: How about inspection?
A: We have the whole inspection system from raw material to end products include Transient test, delay test,mechanical life test and so on.
Q: What is the service offered by company?
A: We have the professional enginer team which can design and develop the mold to arrive different customer requirement.
We also have the sales team to offer good service from pre-sale to after-sale.
